This present invention relates to an apparatus for the capture of radiographic images and metadata associated with radiographic images. More particularly, the present invention relates to an apparatus for the mobile capture of such images.

Drive better outcomes With next-level technology, exceptional versatility and improved scanning views, the CS 3700: Smart-shade matching automatically detects the enamel color of the scan area to identify the ideal match for optimum restorative outcomes. Completing the installation Laser imager back panel Connect the network cable to the network connector on the laser imager. Connect the other end of the network cable to the nearest building network connector. After the laser imager has completed the warm-up cycle, send an image from each modality that will print to the laser imager.

Radiography refers to a general system, or modality, for recording a radiation image from the transmission of X-rays through the body of a patient. Conventional radiography uses a film/screen combination as a capture device while digital radiography can use either a flat-panel detector (DR) or stimulable phosphor plate (CR).

Radiographic examinations are common in health-care institutions, such as hospitals or tertiary care facilities. In some situations patients are transported into special examination rooms equipped for radiography while in other situations mobile radiographic equipment is transported to the location of the patient to obtain radiographs.

Mobile radiographic equipment provides a means to capture X-Ray images of objects using a transportable system generating and projecting an X-Ray beam through an object. Some implementations include only a means for generating an X-ray beam to expose an X-ray image recording plate, whereas other systems may additionally contain a means to retrieve an image from a plate. In general, these systems may be referred to as mobile or portable X-Ray exposure and/or capture systems. It is noted that other references to these systems use terms such as portable or mobile X-Ray generators. It is intended that similar reference refers to these types of systems.

In radiography, information that accompanies an image can be useful. For example, most images are typically stored with the name of a patient, the patient's medical record identification number, the time and date of capture, the body part, the x-ray projection and an identifier to indicate the radiographic technologist that acquired the image. Many types of additional information may also accompany an image such as, but not limited to, the exposure conditions of the radiograph, what type of scatter reducing grid was used, the patient position, the x-ray equipment used or the distance from the x-ray source to the patient.

In the typical practice of mobile radiography, minimal information is recorded with a radiographic image. The radiographic technologists that acquire the images may take notes of this information, or memorize it as x-ray exams are taken, then the information is manually input into a computer system at a later time. This information may subsequently be stored in a database or electronically with digital image data. One common representation for storing this information with an image in a medical facility is to represent the image and the data in a form supported by the DICOM standard.

Devices have been employed to assist in the collection of information relating to the acquisition of an x-ray image. U.S. Pat. No. 5,418,355 (Weil), commonly assigned and incorporated by reference, describes a system for manually collecting information relating to exam techniques using preprinted bar-code charts and portable bar-code reader.

U.S. Pat. No. 4,960,994 (Muller) relates to management information pertaining to radiographic images, describing a cassette system with a rigidly attached memory for storing information related to an x-ray examination within a cassette.

An object of the present invention is to provide an apparatus to aid in the collection of mobile radiographic images with associated metadata. In one arrangement, the present invention provides a means to electronically record patient, exam, equipment, and technique information associated with the capture/recording of a radiographic image.

The present invention can provide a mechanism/means for electronically recording radiographic technique, equipment, and other information associated with a radiographic examination in the temporal or spatial setting of the examination to improve workflow for radiographic image capture and to minimize the likelihood of errors or emissions of data that may accompany entry of such data if not undertaken in temporal association with the examination.

The present invention can provide a means to electronically communicate data from the device to another computer system such that information recorded in association with the examination can be recorded in an electronic format with a digital representation of the radiographic image to which the information relates.

Further, the present invention can provide a means to receive, store, create, display, select, edit and communicate electronic records associated with medical image requests and other information obtained during radiographic examinations.

The present invention has a form factor/shape that allows it to be in contact with, and affixed to, interchangeable x-ray image receptors that, when attached, can be positioned by a radiographic technologist for capturing mobile radiographic images. Such a form factor allows sensors to automatically record information associated with the examination such as the use of scatter reducing grids or the orientation of an image receptor during an examination.

These objects are given only by way of illustrative example, and such objects may be exemplary of one or more embodiments of the invention. Other desirable objectives and advantages inherently achieved by the disclosed invention may occur or become apparent to those skilled in the art. The invention is defined by the appended claims.

According to one aspect of the present invention, there is provided an apparatus for capturing information associated with an x-ray image recordable on an x-ray imaging plate. The apparatus includes a receiving area, a display, a replaceable rechargeable power supply, one or more non-image sensors, and a computer system. The receiving area receives the x-ray image plate or attaches the apparatus to the x-ray imaging plate. The non-image sensors collect information associated with the x-ray image recorded on the x-ray imaging plate. The computer system includes memory, and is configured to receive, measure, store, and subsequently communicate to another computer system, the collected information associated with the x-ray image recorded on the x-ray imaging plate.

According to another aspect of the present invention, there is provided a hand-held apparatus for capturing information associated with an x-ray image recordable on an x-ray imaging plate including a receiving area, a display, one or more non-image sensors, means for collecting data information, and a computer system. The receiving area receives the x-ray imaging plate or attaches the apparatus to the x-ray imaging plate. The non-image sensors collect information associated with the x-ray image recorded on the x-ray imaging plate. The apparatus includes means for collecting sensor data information from the one or more non-image sensors, and means for collecting non-sensor data information from a device in electronic communication with the apparatus. The computer system includes memory, and is adapted to receive and store the non-sensor collected data information and the sensor collected data information.

The foregoing and other objects, features, and advantages of the invention will be apparent from the following more particular description of the preferred embodiments of the invention, as illustrated in the accompanying drawings.

FIG. 1 illustrates an exemplary networked system comprising medical imaging systems, information systems, and picture archiving and communications systems (PACS), one or more mobile radiographic systems, and an x-ray image capture device/camera.

FIG. 2 shows an exemplary mobile x-ray system for imaging a patient with a plurality of equipment that can be associated with the capture of radiographic images.

FIGS. 3A-3C diagrammatically illustrate one embodiment of the present invention, showing a hand-held apparatus with a cavity or receiving area that supports an x-ray imaging plate, and includes a touch screen computer display and a means to attach a scatter reducing grid.

FIGS. 4A-4C illustrate the apparatus of the present invention employed for mobile transport to be used in association with the capture of a mobile radiographic image.

FIG. 5 shows exemplary subsystems and sensors which can be employed with the present invention.

FIG. 6 shows examples of modes of operation of the apparatus of the present invention.

The following is a detailed description of the preferred embodiments of the invention, reference being made to the drawings in which the same reference numerals identify the same elements of structure in each of the several figures.

The present invention is now described with reference to FIGS. 1-6.

FIGS. 3A-3C show an embodiment of the present invention of an apparatus 100 that can be held in a hand of an individual during use of the apparatus. More particularly, the embodiment is an electronic apparatus 100 that can be held in a hand of a user and that enhances the procedures associated with the acquisition of radiographs with a mobile radiography system. This apparatus will be referred to as an x-ray information device or an X-Ray camera. Apparatus 100 is an element of a system of related devices, referred to as a mobile radiography image recording system, that function together to enable enhanced capabilities for portable radiographic imaging.

Apparatus 100 comprises a (built in) personal data assistant (PDA) computer that provides a computer processor system with a battery, a display 500, a user interface, computer memory, wireless electronic communications and one or more self contained non-image sensors. As shown in FIGS. 3A-3C, the apparatus, includes a housing configured to be held in a hand of a user of the apparatus, the housing being formed in a shape with a receiving area or cavity 510 capable of receiving an interchangeable radiographic imaging plate 605. The imaging plate may comprise a computed radiography cassette or a digital radiography image receptor. Use of a PDA is one means to implement several features of the present invention. These features may be implemented in alternative forms by integrating components rather than through the utilization of a pre-integrated PDA device.

The embedded computer system provides a user interface that is programmed to allow a radiographic technologist to create, recall, edit, and store computer records to aid in the capture and recording of information during the process of collecting images with a mobile radiography system.

A database in the computer system receives and stores medical image requests. Records of such requests can be displayed, sorted, and selected by the radiographic technologist. A user interface, shown on display 500, allows additional medical image requests to be entered into the device. New or recalled medical image requests can be selected to identify an electronic record of interest.
